Vertical Cladding Calculator

Last updated: 19 Apr 2025 | Author: Brij | Review By: Irshad

Share on :

Enter the dimensions of the walls, doors, and windows to calculate the total wall area, exact amount of vertical cladding.

Wall Length:

Wall Height:

Number of Walls:

Vertical Cladding Settings

Panel Width:

inches

Panel Height:

feet

Wastage (%):

Deduct Openings (Optional)

Number of Doors:

Door Size (each):

ft²

Number of Windows:

Window Size (each):

ft²

Vertical Cladding Results

Total Wall Area:

ft²

Panels Needed:

panels

Total Cladding (with wastage):

ft²

When installing vertical cladding (like wood, vinyl, or metal panels), accurate measurements are crucial to avoid material shortages or excess waste. This guide explains the formulas used in our Vertical Cladding Calculator and provides real-world examples.

1. Total Wall Area Calculation

First, calculate the total wall area before accounting for openings (doors/windows).

Formula:

$\text{Total Wall Area} = \text{Wall Length} \times \text{Wall Height} \times \text{Number of Walls}$

Example:

Wall Length: 20 ft
Wall Height: 10 ft
Number of Walls: 2

2. Deducting Openings (Doors & Windows)

Subtract the area of doors and windows to get the net wall area.

Formula:

$\text{Net Wall Area} = \text{Total Wall Area} - (\text{Number of Doors} \times \text{Door Area}) - (\text{Number of Windows} \times \text{Window Area})$

Example:

Total Wall Area: 400 ft²
Doors: 2 doors × 21 ft² each = 42 ft²
Windows: 3 windows × 12 ft² each = 36 ft²

400−42−36=322 ft²

3. Calculating Vertical Panels Needed

Determine how many cladding panels are required based on panel dimensions.

Formula:

$\text{Panels per Row} = \left\lceil \frac{\text{Wall Length}}{\text{Panel Width}} \right\rceil$

$\text{Rows per Wall} = \left\lceil \frac{\text{Wall Height}}{\text{Panel Height}} \right\rceil$

$\text{Total Panels} = \text{Panels per Row} \times \text{Rows per Wall} \times \text{Number of Walls}$

Example:

Wall Length: 20 ft
Panel Width: 6 inches (0.5 ft)
Wall Height: 10 ft
Panel Height: 8 ft
Number of Walls: 2

$\text{Panels per Row} =\left\lceil\frac{20}{0.5}\right\rceil=40\text{ panels}$

$\text{Rows per Wall} =\left\lceil\frac{10}{8}\right\rceil=2\text{ rows}$

$\text{Total Panels} =40\times 2\times 2=160\text{ panels}$

4. Adding Wastage (%)

Material wastage (due to cuts, errors, or defects) should be factored in.

Formula:

$\text{Total Cladding Area} = \text{Net Wall Area} \times \left(1 + \frac{\text{Wastage \%}}{100}\right)$

Example:

Net Wall Area: 322 ft²
Wastage: 10%

$322\times(1+0.10)=354.2\,\text{ft}^2$

Real-World Example

Scenario:

Wall Dimensions: 15 ft (length) × 12 ft (height), 2 walls
Openings: 1 door (21 ft²), 2 windows (12 ft² each)
Cladding Panels: 5 inches wide × 6 ft tall
Wastage: 15%

Calculations:

Total Wall Area:

15×12×2=360 ft²

Net Wall Area:

360−21−(2×12)=315 ft²

Panels Needed:

Panels per Row:

$\left\lceil \frac{15\ \text{ft}}{0.4167\ \text{ft}} \right\rceil = 36\ \text{panels} \quad (5\ \text{inches} = 0.4167\ \text{ft})$

Rows per Wall:

$\left\lceil \frac{12\ \text{ft}}{6\ \text{ft}} \right\rceil = 2\ \text{rows}$

Total Panels:

$36 \times 2 \times 2 = 144\ \text{panels}$

Total Cladding (with wastage):

$315\ \text{ft}^2 \times 1.15 = 362.25\ \text{ft}^2$

Final Estimate:

Panels Required: 144 panels
Total Cladding Area Needed: 362.25 ft²

Conclusion

Using this Vertical Cladding Calculator, you can:

✔ Measure total wall area accurately.
✔ Deduct openings (doors/windows).
✔ Calculate exact panel counts.
✔ Adjust for material wastage.

Try the calculator above and simplify your cladding project planning!
